? AC1200 Dual Band Wi-Fi Speed
? High Performance Dual Core CPU
? 16MB Flash and 128MB DDR3
? 5 x Gigabit Ethernet Ports + 1 USB 3.0 Ports
? 4 x 5dBi High Gain Antennas
? VPN Clients and DDNS Support
? 2-IN-1 WiFi Router / Access Point
? MIMO Technology Support
Model |
WR1300 |
Hardware Features |
Processor |
Dual-Core CPU |
Flash |
16MB |
DDR |
128MB |
Antenna |
4× Fixed Omni-Directional Antennas |
Interface |
1× 1000/100/10 Mbps WAN Port |
4× 1000/100/10 Mbps LAN Ports |
USB |
USB 3.0 |
Button |
WPS Button, Reset Button |
External Power Supply |
12 V / 1 A |
Dimensions ( W x D x H ) |
204.8 x 137. 5 x 38. 3mm |
Wireless Features |
Wireless Standards |
IEEE 802.11ac/n/a 5 GHz |
IEEE 802.11n/b/g 2.4 GHz |
Frequency |
5 GHz, 2.4 GHz |
Signal Rate |
867 Mbps (5 GHz), 300 Mbps (2.4 GHz) |
Compatible with 802.11a/b/g/n/ac Wi-Fi standards |
Transmit Power |
CE: <20dBm(2.4 GHz), <23dBm(5.15 GHz~5.25 GHz) |
FCC:<30dBm(2.4 GHz & 5.15 GHz~5.825 GHz) |
Wireless Modes |
Enable/Disable Wireless Radio, WMM |
WEP, WPA/WPA2, |
Wireless Functions |
WPA-PSK/WPA2-PSK |
Software Features |
WAN Type |
Dynamic IP/Static IP/PPPoE |
Management |
Parental Control |
Guest Network |
DHCP |
Server, DHCP Client List, Address Reservation |
Dynamic DNS |
Compatible with 15 more DDNS providers |
Guest Network |
2.4 GHz guest network × 1 |
5 GHz guest network × 1 |
NAT |
Port Forwarding, Port Triggering, UPnP, DMZ |
VPN Client |
PPTP/L2TP/OpenVPN/WireGuard |
Others |
Package Contents |
AC1200 Wi-Fi Router |
Power Adapter |
RJ45 Ethernet Cable |
Quick Installation Guide |
System Requirements |
Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS,
NetWare, UNIX or Linux
|
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0,
or other Java-enabled browser
|
Cable or DSL Modem |
Subscription with an internet service provider (for internet access) |
