Materials |
Steel, Plastic, Tempered Glass |
|
Dimensions (L x W x H) |
496 x 217 x 469 mm |
|
|
Motherboard Support |
Mini ITX, Micro ATX, ATX, SSI CEB*, E-ATX*, (*up to 12" x 10.7" motherboards, may impact cable management feature) |
|
|
|
2.5" / 3.5" Drive Bays (Combo) |
2 (Max.2) |
|
2.5" Drive Bays |
4 (Max.6) |
|
I/O Panel |
2 x USB 3.2 Gen 1 (USB 3.0), 1 x 3.5mm Audio Jack,1 x 3.5mm Mic Jack, 1x ARGB/PWM Hub (may depend on region and model) |
|
Pre-installed Fans - Front |
3x 120mm 650~1800RPM SickleFlow PWM ARGB |
|
Pre-installed Fans - Rear |
1x 120mm 1000-1400RPM MasterFan Lite |
|
Fan Support - Top |
3x 120mm, 2x 140mm |
|
Fan Support - Front |
3x 120mm, 2x 140mm |
|
Fan Support - Rear |
1x 120mm |
|
Radiator Support - Top |
120mm, 240mm, 360mm, (44mm max motherboard component height) |
|
Radiator Support - Front |
120mm, 140mm, 240mm, 280mm, 360mm, (75mm clearance) |
|
Radiator Support - Rear |
120mm |
|
Clearance - CPU Cooler |
165mm / 6.49" |
|
Clearance - PSU |
180mm/7.08" |
|
Clearance - GFX |
410mm/16.1" |
|
|
Dust Filters |
Top, Front, Bottom |
|
Power Supply Support |
Bottom Mount, ATX |
|
|
Model Number |
MCB-B520-KGNN-RGA |
|
