Model |
300 Mbps 4G LTE Mobile Wi-Fi |
Dimensions |
97 x 61 x 15.5mm |
Weight |
TBD |
Form |
MiFi / Pocket Router |
Communication
System (WAN) |
Chipset |
Qualcomm MDM9x07 / MDM9x25 |
Frequency Bands |
LTE |
Band 1, 3, 5, 7, 8, 38, 40, 41 |
UMTS |
Band 1, 8 |
GSM |
900MHz, 1800MHz, 850MHz |
Bandwidth |
LTE Band |
1.4/3/5/10/15/20 MHz |
Modulation |
Downlink |
QPSK/16-QAM/64-QAM |
Uplink |
QPSK/16-QAM |
Antenna |
Primary |
Internal |
Diversity |
Internal, UMTS Optional |
RF Power Level |
LTE FDD |
Power Class 3 (23 +/-2dBm) |
UMTS |
Power Class 3 (24 +1.7/-3.7dBm) |
EDGE |
Power Class E2 (GSM850/900: 27dBm; DCS/PCS: 26dBm) |
GPRS |
GSM850/900 Power Class 4: 33dBm; DCS/PCS Power Class 1: 30dBm) |
Data Rate |
4G |
3GPP R10, Cat. 4, Downlink/Uplink up to 150Mbps/50Mbps |
3G |
3GPP R7 Downlink/Uplink up to 42Mbps/5.76Mbps |
2G |
EGPRS Class33 Downlink/Uplink up to 296Kbps/236.8Kbps |
WLAN |
Wi-Fi |
Chipset |
RealTek 8192ES |
Frequency |
2.4GHz |
Protocol |
802.11b/g/n |
Channel |
1~13 |
Antenna |
Internal, 2 x 2 |
Data Rate |
802.11b |
Up to 11 Mbps |
802.11g |
Up to 54 Mbps |
802.11n |
Up to 300 Mbps |
Feature |
Interface |
USB |
USB2.0 |
USIM |
Single, 2FF |
MicroSD |
Up to 32GB |
LED |
POWER |
Power/Battery Status Indicator |
Network |
4G/3G/2G Network Status Indicator |
Wi-Fi |
Wi-Fi Status Indicator |
Message |
New SMS Indicator |
Memory |
ROM |
4Gbits |
RAM |
2Gbits |
WebUI |
System |
Connection Status |
Statistics |
Samba (optional) |
Device Management |
Power Mangement |
Andoid/iOS App Management |
Mobile
Service |
SMS Manager |
Automatic APN matching according to USIM |
Auto Data Connection |
USSD Service |
PIN/PUK Management |
Network Mode Selection(2G/3G/LTE/Auto) |
Router |
USB RNDIS Device |
Up to 10 Wi-Fi users/devices |
DHCP Server |
IPv4/v6 |
VPN Passthrough |
Firewall |
WPS |
Security via WEP, WPA-PSK, WPA2-PSK |
Wi-Fi Settings |
Battery |
Type |
Li-ion Polymer Battery |
Capacity |
2000mAh |
Endurance |
5-6 hours (normal network situation) |
Operation System |
Windows |
XP/7/8/10 |
MAC OS |
10.7+ |
Linux |
Ubuntu 13.04+ |
Browser |
IE9+, Firefox, Google Chrome, Safari, Opera |
Environment |
Power Supply |
USB, 5V1A |
Working Temperature |
0°C to 35°C |
Storage Temperature |
-20°C to 60°C |
Certification |
3GPP Compliance |
CE/FCC/GCF, upon customer's requirement |
Meterial |
RoHS |
