Model |
WE4000 |
Chipset |
Intel AX200NGW |
Antenna |
External 2x5dBi Antenna |
Drive Free |
Not Support |
Physical Interface |
PCIE-X1 |
USB |
Not Support |
Wireless Frequency |
2.412-2.472GHz:574Mbps |
5.180-5.825GHz:2400Mbps |
Bluetooth |
Bluetooth 5.0 |
Wireless Standard |
IEEE802.11ax / ac/ a/ b/ g /n |
Compatible Card Slot |
PCIE-16X/PCIE-4X/PCIE-8X/PCIE-1X; Graphics slot |
Transmit Power |
WiFi: 19.5 dBm(max) |
BT:10 dBm |
Scope of Application |
Desktop PC,Except Mac |
Web Environment |
Gigabit and above networks |
Product Size |
Size: 72*46mm; Antenna Size: 94.5*221.5mm |
Support OS |
Windows10 (64bit) |
Working Environment |
Working Temperature: 0 C~40 C |
Storage Temperature: -40 C~70 C |
Working Humidity: 10%~90%RH Non-condensing |
Storage Humidity: 5%~90%RH Non-condensing |
