GO-SW-5G |
GO-SW-8G |
|---|
Switching Fabric |
10 Gbps |
16 Gbps |
Standards |
- IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
- IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
- IEEE 802.3ab 1000BASE-T Gigabit Ethernet (twisted-pair copper)
- ANSI/IEEE 802.3 NWay auto-negotiation
- IEEE 802.3x Flow Control
- IEEE 802.3az Energy-Efficient Ethernet (EEE)
|
Protocol |
CSMA/CD |
Data Transfer Rat |
- Ethernet:
- 10 Mbps (half duplex), 20 Mbps (full duplex)
- Fast Ethernet:
- 100 Mbps (half duplex), 200 Mbps (full duplex
- Gigabit Ethernet:
|
Topology |
Star |
Network Cables |
- 10BASE-T:
- UTP CAT 3, 4, 5/5e (100 m max.)
- EIA/TIA-586 100-ohm STP (100 m max.)
- 100BASE-TX:
- UTP CAT 5/5e (100 m max.)
- EIA/TIA-568 100-ohm STP (100 m max.)
|
Media Interface Exchange |
Auto MDI/MDIX adjustment for all ports |
LED Indicators |
- Per port: Link/Activity/Speed
- Per device: Power
|
Transmission Method |
Store-and-forward |
MAC Address Table |
2K |
8K |
MAC Address Learning |
Automatic update |
Packet Filtering/Forwarding Rates |
- Ethernet: 14,880 pps per port
- Fast Ethernet: 148,800 pps per port
- Gigabit Ethernet: 1,488,000 pps per port
|
RAM Buffer |
128KB per device |
Jumbo Frames |
9,216 Bytes |
DC Input |
External 5 V/1 A Level "V" Power Adapter |
Power Consumption |
- DC input: 1.67 watts
- AC input: 2.7 watts
|
- DC input: 3.06 watts
- AC input: 3.9 watts
|
MTBF |
815,700 hours |
412,433 hours |
Operating Temperature |
23º to 104º F (0º to 50º C) |
Storage Temperature |
14º to 158º F (-10º to 70º C) |
Operating Humidity |
10% to 90% RH non-condensing |
Storage Humidity |
5% to 90% RH non-condensing |
Dimensions |
3.8 x 3.1 x 1.1 inches
(97 x 79 x 28 mm) |
5.16 x 3.23 x .9 inches
(128 x 68.5 x 25.4 mm) |
Weight |
3.688 ounces (105 grams) |
4.88 ounces (138.3 grams) |
Certifications |
- FCC Class B
- ICES-003 Class B
- CE Class B
- C-Tick Class B
- VCCI Class B
- cUL/UL
- CCC
- Anatel
- LVD
|
