Panel Size (diagonal)
34" OLED
Display Viewing Area (HxV)
800.06 x 337.06 mm
Panel Backlight/ Type
OLED
Display Surface(non-glare/ glare)
Anti-Reflection
Color Saturation
99% DCI-P3
True Resolution
3440 x 1440 (WQHD)
Pixel Pitch
0.2315(H) x 0.2315(V) mm
Brightness
250 cd/m² (Typ, SDR APL 100%); 1000 cd/m² (Typ, HDR APL 3%)
Contrast Ratio
1.5M:1
Viewing Angle
178°(H)/178°(V)
Display Colors
10bit (1.07B)
Response Time
0.03ms GTG
Refresh Rate
175Hz
HDR
VESA DisplayHDR True Black 400
VESA Certified ClearMR
ClearMR 10000
Flicker-free
Yes
Connectivity
2 x HDMI 2.1
1 x Displayport 1.4
1 x USB Type-C (Alternate Mode; Upstream port; Power Delivery up to 18W)
2 x USB 3.2 Downstream ports
1 x USB 3.2 Upstream port
1 x Earphone Jack
1 x Microphone Jack
Earphone Jack
Yes
Speaker
3W x 2
Unique Features
Tactical Switch
OSD Sidekick *
Black Equalizer 2.0
Dashboard
Crosshair
Timer
Counter
Eagle Eye
PiP/PbP
Auto-Update
KVM
6 axis Color Control
Apply Picture Mode
HDMI-CEC
Power Type
Power Board Build-in
Power Consumption
44W**
Power Saving Mode
<0.5W
Power Off Mode
<0.3W
Voltage
AC 100-240V ~ 50/60Hz
Tilt(angle)
-5°~+20°
Swivel(angle)
±30°
Height Adjustment (mm)
130 mm
VESA Wall Mounting(mm)
100*100 mm
Kensington lock
Yes
Phys. Dimension with Stand(WxHxD)
811.7 x 595.3 x 244.3 mm
Phys. Dimension w/o stand (WxHxD)
811.7 x 361.2 x 105.8 mm
Box Dimension (WxHxD)
990*527*238 mm
Net Weight with stand (Esti.)
9.86 kg
Net Weight without stand (Esti.)
6.68 kg
Gross Weight (Esti.)
12.5 kg
Accessories
Power cable/HDMI 2.1 cable/DP cable/USB cable/QSG/Warranty card
Note
*To enable OSD Sidekick (integrated in GCC), it requires connection between PC and monitor with HDMI/DP cable.
**The test condition follows CEC standards.
