Form factor |
2.5" |
Interface |
SATA Rev. 3.0 (6Gb/s) — with backwards compatibility to SATA Rev. 2.0 (3Gb/s) |
Capacities1 |
480GB, 960GB, 1920GB, 3840GB, 7680G |
NAND |
3D TLC |
Self-Encrypting Drive (SED) |
AES 256-bit encryption |
Sequential Read/Write |
480GB – 560MBs/470MBs
960GB – 560MBs/530MBs
1920GB – 560MBs/530MBs
3840GB – 560MBs/530MBs
7680GB – 560MBs/530MBs |
Steady-state 4k random read/write |
480GB – 94,000/41,000 IOPS
960GB – 94,000/65,000 IOPS
1920GB – 94,000/78,000 IOPS
3840GB – 94,000/59,000 IOPS
7680GB – 94,000/34,000 IOPS |
Quality of service (latency)3,4,5(99.999) |
Read/Write
480GB – 180/110 uSec
960GB – 3840GB – 200/300 uSec
7680GB – 240/170 uSec |
Typical latency - read/write |
<200 µs / <30 us3,4,5 |
Hot-plug capable |
|
Static and dynamic wear levelling |
|
Enterprise SMART tools |
Reliability tracking, usage statistics, life remaining, wear levelling, temperature |
Hardware-based power loss protection |
|
Endurance |
480GB – 876TBW6, 1 DWPD (5 years)7, 1.66 DWPD (3 years)7
960GB – 1752TBW6, 1 DWPD (5 years)7, 1.66 DWPD (3 years)7
1920GB – 3504TBW6, 1 DWPD (5 years)7, 1.66 DWPD (3 years)7
3840GB – 7008TBW6, 1 DWPD (5 years)7, 1.66 DWPD (3 years) 7
7680GB – 14016TBW6, 1 DWPD (5 years)7, 1.66 DWPD (3 years)7 |
Power consumption |
Idle: 1.30W
Average: 1.45W
Max read: 1.6W
Max write: 3.6W |
Storage temperature |
-40? ~ 85? |
Operating temperature |
0? ~ 70? |
Dimensions |
69.9mm x 100mm x 7mm |
Weight |
92.34g |
Vibration operating |
2.17G Peak (7–800Hz) |
Vibration non-operating |
20G peak (10–2000Hz) |
MTBF |
2 million hours |
Warranty/support |
Limited 5-year warranty with free technical support8 |
