- Dimensions
-
99.8*98*25mm
-
- PoE Ports
-
RJ45
Standard: Compliant with 802.3 af/at Powered Devices
PoE Ports: Port 1- Port 4
PoE Power Budget: 65 W
-
- Interfaces
-
5× 10/100/1000Mbps Ports, Auto-Negotiation, Auto MDI/MDIX
-
- External Power Supply
-
External Power Adapter (Output: 53.5V/1.31A)
-
- Installation
-
Desktop
Wall Mount
-
- Standards and Protocols
-
IEEE 802.3x Flow Control
-
- Data Rates
-
10/100/1000 Mbps at Half Duplex
20/200/2000 Mbps at Full Duplex
-
- Jumbo Frame
-
9 KB
-
- Mac Address Table
-
2K
-
- Max Power Consumption
-
3.13W(220 V / 50 Hz, no PD connected)
75.15W(220 V / 50 Hz, with 65W PD connected)
-
- Max Heat Dissipation
-
10.64 BTH/h (no PD connected)
255.51 BTH/h(with 65W PD connected)
