- Dimensions
-
99.8*98*25mm
-
- PoE Ports
-
RJ45
Standard: Compliant with 802.3 af/at Powered Devices
PoE Ports: Port 1- Port 4
PoE Power Budget: 40 W
-
- Interfaces
-
6× 10/100 Mbps Ports, Auto-Negotiation, Auto MDI/MDIX
-
- External Power Supply
-
External Power Adapter (Output: 53.5V/0.81A)
-
- Installation
-
Desktop
Wall Mount
-
- Standards and Protocols
-
IEEE 802.3x Flow Control
-
- Data Rates
-
10/100 Mbps at Half Duplex
20/200 Mbps at Full Duplex
-
- Jumbo Frame
-
2 KB
-
- Mac Address Table
-
2K
-
- Max Power Consumption
-
1.87W(220 V / 50 Hz, no PD connected)
44.8W(220 V / 50 Hz, with 40W PD connected)
-
- Max Heat Dissipation
-
6.34 BTH/h (no PD connected)
152.32 BTH/h(with 40W PD connected)
