- Dimensions
-
171*98*27 mm
-
- PoE Ports
-
RJ45
Standard: Compliant with 802.3 af/at Powered Devices
PoE Ports: Port 1- Port 8
PoE Power Budget: 65 W
-
- Interfaces
-
10× 10/100 Mbps Ports, Auto-Negotiation, Auto MDI/MDIX
-
- External Power Supply
-
External Power Adapter (Output: 53.5V/1.31A)
-
- Installation
-
Desktop
Wall Mount
-
- Standards and Protocols
-
IEEE 802.3x Flow Control
-
- Data Rates
-
10/100 Mbps at Half Duplex
20/200 Mbps at Full Duplex
-
- Jumbo Frame
-
2 KB
-
- Mac Address Table
-
2K
-
- Max Power Consumption
-
2.96W(220 V / 50 Hz, no PD connected)
77.52W(220 V / 50 Hz, with 65W PD connected)
-
- Max Power Consumption
-
10.064 BTH/h (no PD connected)
263.568 BTH/h(with 65W PD connected)
