Specifications
Details |
|---|
Product code |
RB5009UG+S+IN |
Architecture |
ARM 64bit |
CPU |
88F7040 |
CPU core count |
4 |
CPU nominal frequency |
350-1400 (auto) MHz |
RouterOS license |
5 |
Operating System |
RouterOS (v7 only) |
Size of RAM |
1 GB |
Storage size |
1 GB |
Storage type |
NAND |
MTBF |
Approximately 200'000 hours at 25C |
Tested ambient temperature |
-40°C to 60°C |
|
|
Powering
Details |
|---|
Number of DC inputs |
3 (DC jack, PoE-IN, 2-pin terminal) |
DC jack input Voltage |
24-57 V |
2-pin terminal input Voltage |
24-57 V |
Max power consumption |
20 W |
Max power consumption without attachments |
14 W |
FAN count |
Passive |
PoE in |
802.3af/at |
PoE in input Voltage |
24-57 V |
Ethernet
Details |
|---|
10/100/1000 Ethernet ports |
7 |
Number of 2.5G Ethernet ports |
1 |
Fiber
Peripherals
Details |
|---|
Number of USB ports |
1 |
USB Power Reset |
Yes |
USB slot type |
USB 3.0 type A |
Max USB current (A) |
1 |
Other
Details |
|---|
CPU temperature monitor |
Yes |
Certification & Approvals
Details |
|---|
Certification |
CE, EAC, ROHS |
Included parts
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
