FAN Specification
Mounting hole spacing
50x50 mm
Cable length
20cm + 30cm NA-EC1 extension cable
Rotational speed (+/- 10%)
3000 RPM
Rotational speed with L.N.A. (+/- 10%)
2400 RPM
Rotational Speed with U.L.N.A. (+/- 10%)
1600 RPM
Acoustical noise
19,3 dB(A)
Acoustical noise with L.N.A.
14,5 dB(A)
Acoustical noise with U.L.N.A.
8,2 dB(A)
Static pressure
2,18 mm H2O
Static pressure with L.N.A.
1,41 mm H2O
Static pressure with U.L.N.A.
0,61 mm H2O
Max. input current
0,12 A
Scope of delivery
- Low-Noise Adapter (L.N.A.)
- Ultra-Low-Noise Adapter (U.L.N.A.)
- 3:4-Pin Adaptor
- 30cm Extension Cable
- 4 Vibration-Compensators
- 4 Fan Screws
