Release Date |
10 / 08 / 2015 |
Unit Weight |
1838g |
Unit Dimension (cm) |
14 x 15 x 8.5 |
Form Factor Type |
ATX |
Auto Fan Speed |
Yes |
Bearing Type |
Nano-Tech bearing |
Budget |
Yes |
Cable Length |
50cm |
Cable Type |
non sleeved |
Certification |
CE/RoHS/REACH/EUP6 |
Color |
black |
Connectors |
20+4pin 1PCS; 12V4pin 1PCS; SATA 4PCS;IDE(Molex)4pin 2PCS
|
Cooling |
12cm active cooling |
Dual Rail 12V |
Yes |
Efficiency |
>80% efficient |
Fan Size (cm) |
12 x 12 x 25 |
Fan Type |
DC12V Nano-Tech |
Features |
Intel Core 2, Core 2 Due, Core 2 Extreme, Celeron, Pentium | AMD Athlon 64X2,AMD Athlon 64 FX,AMD Athlon 64, Sempron |
Frequency |
50~60 Hz |
Gaming |
No |
Hold Up Time |
16 ms(min) |
Housing |
Steel |
LED Fan |
No |
Life Expectancy (HRS) |
100.000 |
Material |
SECC |
Material Thickness (mm) |
0.6 |
Modular Cables |
No |
Noise Level (dBA) |
21.0 |
Nominal Power (w) |
600 |
Operating Temperature (°C) |
-20 to 70 |
Packaging Includes |
1. User's Manual
2. Mounting screws 5pcs
3.1.5M EU power cable
|
Packaging |
Retail box |
Packaging Type |
Retail Color Box |
P.G. Signal |
100~500ms |
Rated Current (A) |
100~240 Vac |
Silent |
Yes |
Specifications |
V2.31 |
Storage Temperature (°C) |
-20 to 70 |
Voltage AC (INPUT) |
100 ~ 240 |
Voltage Protection |
+12V trip point 13.4V - 15.6V +5V trip point 5.74V - 7.0V +3.3V trip point 3.76V - 4.3V
|
Warranty |
2 Years |
