Standards and Protocols |
HomePlug AV2, HomePlug AV, IEEE 1901, IEEE 802.3, IEEE 802.3u,
IEEE 802.3ab, IEEE 802.11b/g/n (2.4GHz), IEEE 802.11a/n/ac (5GHz) |
|---|
Interface |
TL-WPA7517: 1 Gigabit Ethernet Port
TL-PA7017: 1 Gigabit Ethernet Port |
|---|
Button |
Pair, Reset, Wi-Fi Clone, LED On/Off |
|---|
Power Consumption |
TL-WPA7517: Maximum: 11W, Typical: 6.5W
TL-PA7017: Maximum: 2.9W, Typical: 2.6W |
|---|
LED Indicator |
Power, Powerline, Ethernet, Wi-Fi (2.4GHz), Wi-Fi (5GHz) |
|---|
Dimensions ( W x D x H ) |
TL-WPA7517: 2.7 × 1.4 × 4.9 in. (69.5 × 35 × 124.1 mm)
TL-PA7017: 2.0 × 1.1 × 2.6 in. (52 × 28.5 × 65 mm) |
|---|
Range |
Up to 300 meters/1000 feet over existing electrical wiring |
|---|
Compatibility |
Compatible with all HomePlug AV & AV2 standard powerline adapters |
|---|
Transmission Speeds |
Powerline: Up to 1000 Mbps
Ethernet: 10/100/1000 Mbps |
|---|
