MikroTik CRS309-1G-8S+IN 1xGbE LAN 8x10GbE SFP+ Cloud Router Switch
  • MikroTik CRS309-1G-8S+IN 1xGbE LAN 8x10GbE SFP+ Cloud Router Switch
  • MikroTik CRS309-1G-8S+IN 1xGbE LAN 8x10GbE SFP+ Cloud Router Switch
  • MikroTik CRS309-1G-8S+IN 1xGbE LAN 8x10GbE SFP+ Cloud Router Switch
  • MikroTik CRS309-1G-8S+IN 1xGbE LAN 8x10GbE SFP+ Cloud Router Switch
  • MikroTik CRS309-1G-8S+IN 1xGbE LAN 8x10GbE SFP+ Cloud Router Switch

MikroTik CRS309-1G-8S+IN 1xGbE LAN 8x10GbE SFP+ Cloud Router Switch

71226
Mikrotik
95 000 Ft
Adóval együtt
Mennyiség
1 Elem

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

Leírás

The CRS309-1G-8S+ is a very compact, yet powerful networking switch. It has eight SFP+ slots, supporting up to 10 Gbit module in each, which results in a total switching capacity of 162 Gbps and total non-blocking throughput of 81 Gbps.

The device also has dual-core 800 MHz CPU, 512 MB RAM, a management Ethernet port with PoE power input, RS232 serial port, a grounding terminal and is capable of dual boot (choose which operating system you prefer, RouterOS, or SwOS).



Specifications

Details
Product code CRS309-1G-8S+IN
Architecture ARM 32bit
CPU 98DX8208
CPU core count 2
CPU nominal frequency 800 MHz
Dimensions 272 x 158 x 44 mm
License level 5
Operating System RouterOS / SwitchOS
Size of RAM 512 MB
Storage size 16 MB
Storage type FLASH
Tested ambient temperature -40°C to 70°C


Powering

Details
PoE in 802.3af/at
PoE in input Voltage 18-57 V
Number of DC inputs 2 (PoE-IN, DC jack)
DC jack input Voltage 12-57 V
Max power consumption 23 W
Max power consumption without attachments 17 W


Ethernet

Details
10/100/1000 Ethernet ports 1


Fiber

Details
SFP+ ports 8


Peripherals

Details
Serial port RS232


Other

Details
CPU temperature monitor Yes



Included parts

Termék részletei
Mikrotik
71226
1 Elem

Megadott referenciák

ean13
5996409327976
MPN (Gyártói cikkszám)
CRS309-1G-8S+IN
